2/5: Mission statement

"To develop as a leading microelectronics company of Pakistan with global recognition"

3/5: Solutions offered

Chip photograph

4/5: RF PWM Generator

Initial measurements for RF-PWM generator completed at 350 MHz. The circuit is digitally controlled and available as block module for integration. It employs a DLL for stable phase generation. Measurements are underway for 700 MHz benchmark.

5/5: Chipsation addresses the following areas in IC design

Have fun with slides!

These slides can contain anything a webpage can! HTML, Javascript, images, flash or whatever! They're completely easy to edit and add to as well, no need to bother editing or even going anywhere near some confusing Javascript files, simply add a <div></div> tag with your slider content to the "slides" contain - it takes just seconds to do!

These slides work using the absolutely wonderful lightweight jQuery plugin jFlow, originally written by Kean Loong and modified by both Mauro Belgiovine and spyka Webmaster. The script has been licensed under the open source MIT license, so feel free to play around and modify it as much or as little as you wish!

NextPrev

  • News

    • Chipsation now offers IC design trainings to academia.

    • Chipsation tests digitally controlled RF-PWM generator at 350 MHz.

    • Development of PLL IP initiated for 1 GHz.

  • Links

    • mbkweb - Software development

Introduction


Chipsation SMC-PVT LTD is a Pakistan-based private fabless integrated circuit start-up incorporated under the Companies Ordinance, 1984 (XLVII of 1984). We provide design, consultancy and training services in the area of integrated circuits. Chipsation was founded with an aim to establish a strong footprint of Silicon industry in Pakistan. Chipsation prides itself in R&D proto-typing and proof-of-concept IC development.
Solutions offered:

  • Full custom IC design
  • IP block licensing
  • Design consultancy
  • Training
